Inventory Simulation — Streamlit Web App

Turn a Python inventory simulation into a single-page web app your team can use.
The app lets you test fixed-cycle replenishment under deterministic and stochastic demand, visualize Demand / Orders / IOH, and compare simple vs lead-time-aware ordering.

• Click Run simulation once; after that, any parameter change auto-recomputes and redraws.
• Results are reproducible (fixed random seed).
• Engine modules remain as-is, wrapped with a minimal Streamlit UI.

🎥 Full Tutorial Video

Click the image below to open the full video tutorial on YouTube:

Features

• Deterministic and stochastic demand simulations
• Simple Ordering vs Lead-time Ordering (receipt timing aligned with cycle end)
• Compact 3-panel chart (Demand / Orders / IOH)
• Inline Quick Context cards (core inputs at a glance)
• KPIs: Stockout days, Min IOH, Avg IOH
• Auto re-run after initial click

Live Demo & Deploy It Yourself

This app is deployed on Streamlit Community Cloud:
👉 https://supplyscience-inventory.streamlit.app/

You can deploy your own copy to Streamlit Community Cloud by connecting your GitHub repo and selecting app.py as the main file.

Architecture

Streamlit UI (app.py)
↓
Inventory Models (pydantic) — inventory_models.py
↓
Simulation Engine (pandas / numpy) — inventory_analysis.py

• The UI only orchestrates inputs, rendering, and calling the existing engine.
• You can later expose the engine via FastAPI or integrate with other frontends.

Prerequisites

• Python 3.10+
• Git (optional)
• Inventory Management Tutorial Source Code: https://github.com/samirsaci/tuto_inventory
• One of:
  • Linux: uv (recommended) or pip
  • Windows: pip (PowerShell / Command Prompt)

If you don’t have Python, install it from python.org or via your OS package manager.

Project structure

tuto_inventory /
├─ app.py
├─ requirements.txt
└─ inventory/
├─ init.py
├─ inventory_analysis.py
└─ inventory_models.py

Keep your inventory_analysis.py and inventory_models.py as-is. Ensure inventory/__init__.py exists (can be empty).

Setup

Option A — Linux with uv (fast & clean)

# Install uv if needed
curl -LsSf https://astral.sh/uv/install.sh | sh

# Create a virtual environment and activate it
uv init
uv venv
source .venv/bin/activate

# Install
uv pip install -r requirements.txt

---

Option B — Windows (PowerShell or CMD) using pip**

mkdir tuto_inventory
cd tuto_inventory
py -m venv .venv
.\.venv\Scripts\activate

pip install -r requirements.txt

---

How to Use

# Run the app
streamlit run app.py

1. In the sidebar, set:
   • D (annual demand), T_total (days), LD (lead time), T (cycle), Q (order qty), initial_ioh (initial stock), sigma (daily demand std. dev.), and Method.
2. Click Run simulation (first time only).
3. Adjust any parameter: the app auto-recomputes.
4. Read Quick Context and KPIs.
5. Interpret the Demand / Orders / IOH chart.

Reproducibility: the app uses a fixed NumPy seed (1991).

Ready-Made Scenarios (for demos)

Defaults often used: D = 2000, T_total = 365 ⇒ D_day ≈ 5.48.
With T = 10 → Q ≈ 55 and initial_ioh ≈ 55. Keep sigma = 0 unless noted.

Hook 1

“What if your inventory touched zero without ever stocking out?”

Scenario 1 — Lead time = 1 (receive next day)
Set: LD=1, T=10, Q≈55, initial_ioh≈55, sigma=0, Method: Simple Ordering
See: IOH drains to ~0 at cycle end; receipt next day → no negatives (clean sawtooth).

---

Hook 2

“Same policy, +1 day lead time—what breaks first?”

Scenario 2 — Lead time = 2 (receive two days later)
Set: LD=2, T=10, Q≈55, initial_ioh≈55, sigma=0, Method: Simple Ordering
See: Receipt arrives late; IOH dips below zero → stockouts (timing issue).

---

Hook 3

“Can we fix stockouts by just ordering more?”

Scenario 3 — Keep timing, increase quantity
Set: LD=2, T=10, Q≈ D_day × (T + (LD−1)) ≈ 60, initial_ioh=60, sigma=0, Method: Simple Ordering
See: Negatives avoided but excess inventory (higher holding costs).
Lesson: Treats the symptom (level), not the cause (timing).

---

Hook 4

“What if we keep quantity but fix the timing?”

Scenario 4 — Anticipate lead time (lead-time-aware trigger)
Set: LD=2, T=10, Q≈55, initial_ioh≈55, sigma=0, Method: Lead-time Ordering
See: Receipt realigns with cycle boundary; stable service without excess.
Interpretation: Approx. ROP ≈ D_day × LD.

---

Hook 5

“What does the EOQ sawtooth actually look like?”

Scenario 5 — EOQ cycle, lead time = 1 (manual)
Set: LD=1, Q=400, T≈73, initial_ioh=400, sigma=0, Method: Simple Ordering
See: Classic EOQ sawtooth; avg IOH ≈ Q*/2; no negatives.

---

Hook 6

“Add uncertainty—does timing still save you?”

Scenario 6 — Stochastic demand (Normal), lead time = 5
Set: LD=5, T=10, Q≈55, initial_ioh≈55, sigma=2.5, Method: Simple Ordering
See: IOH fluctuates; stockouts can appear despite fixed timing.
Lesson: You need safety stock for demand/lead-time variability.

Troubleshooting

• ImportError
  Ensure inventory/__init__.py exists and both engine files are in inventory/.

• Blank page / chart not shown
  Click Run simulation once; then changes auto-recompute.

• Charts not visible
  Confirm matplotlib is installed and no ad-blocker is blocking Streamlit content.

• Different numbers vs video
  Check that your inputs match the scenario values above.

Roadmap

These are just suggestions to help you pursue the exercise.

• Add CSV export of results (table + st.download_button)
• Add Safety Stock / ROP helpers for stochastic cases
• Package the engine as a FastAPI microservice
• Deploy on Streamlit Community Cloud
